ELBO CONTROLLI E346

Year2015ManufacturerELBO CONTROLLICategoryTool Presetting MachinesConditionUsedLocationUnited Kingdom
Ref87

Description

Overview

Supplied by the seller

X-axis of 14.2"(360mm) and a Z-axis of 18.1" (460mm), The vision system for tool measuring includes a TFT 9" color touch screen with 110mm x 200mm image size and 25X magnification. The unit comes with a standard cutting edge inspection feature to get a crystal clear image of the condition of the cutting edge before measuring the tool. The presetter comes standard with the newly developed post-processing software, including 50 post-processors that translate measured data into CNC code. This data can then be put on a USB stick and tooling data can be inserted into the machine's CNC. These tool presetters are designed with a base and column of natural granite that guarantees the least thermal expansion of all construction materials. Interchangeable rotating spindle-holders with manual mechanical braking of the spindle-holders' rotation are available. E.g. CAT/ISO/BT, HSK, Capto, KM, VDI.

Specifications

Manufacturer
ELBO CONTROLLI
Year
2015
Weight
77 kg
Measuring Range Z
460 mm
Measuring Range X
361 mm
Diameter
340 mm
View full spec sheetHide full spec sheet
  • Includes 40 Taper Spindle holder.
  • Presetter Stand

As supplied by the seller. Figures are converted between systems where a unit applies; anything without one is shown as quoted.
