Description
Overview
Supplied by the seller
This large-capacity, rare machine is currently in full production and remains in daily use within a leading UK precision engineering PLC. Maintained to high operational standards, it will be available for release at the end of the first quarter of 2026. This represents an exceptional opportunity to acquire a premium machine that has been operated in a controlled, professional production environment.
Please contact us to make an appointment to view.
Included
- Chiller
- Interlock Guards
- Paper Filtration System
- Renishaw Probing
- Swarf Conveyor
- Swarf Skip
Specifications
- Manufacturer
- MANDELLI
- Year
- 1999
- Control
- Siemens Sinumerik 840D
- Weight
- 80,000 kg
- Dimensions
- 512 x 433 x 193
- X
- 4,000 mm
- Y
- 2,500 mm
- Z
- 2,200 mm
- Power
- 40.0 kw
- RPM
- 3000.0 rpm
- # ATC
- 100.0
- Taper
- SK50
- Pallet-W
- 2,000 mm
- Pallet-L
- 1,600 mm
- # Axis
- 5.0
View full spec sheetHide full spec sheet
- Serial No
- 7525
- MFD
- March 1999
- Pallet Size
- 2000 x 1600mm
- Max Pallet Load; 8000kg
- X Axis Traverse
- 4000mm
- Y Axis Traverse
- 2500mm
- Z Axis Traverse
- 2200mm
- Feeds
- 5 – 15000mm/min
- Rapids
- 15m/min
- Maximum Component Diameter
- 3200mm
- Maximum Height of Component
- 2500mm
- B Axis Rotation
- 0.001 Degrees
- Rapids
- 3 rpm
- Head Rotation
- 90 Degrees From Horizontal to Vertical
- Spindle Speeds
- 20 – 3000rpm
- Spindle Taper
- 50
- Spindle Motor
- 40Kw
- ATC
- 100 Positions
- Swarf Conveyor
- 2 No Metal Gennari
- Coolant
- Flood & Through Spindle
- Foot Print
- 13m x 11m x 4.9m High of Floor,
- Maximum Foundation Depth
- 2.4m
- Approximate Weight
- 80 Ton
Complete With
- Renishaw Probing
- 2 off Capto C4 Right Angled Heads
- SK50 Tooling Package
- Interlock Guards
- Paper Filtration System
- Chiller
As supplied by the seller. Figures are converted between systems where a unit applies; anything without one is shown as quoted.
