HAAS SUPER MINI MILL

Year2010ManufacturerHAASCategoryVertical Machining CentersConditionUsedLocationUnited Kingdom
Ref3

Description

Overview

Supplied by the seller

Free Loading To Suitable Transport. This 2010 Haas Super Mini Mill is a compact, versatile vertical machining centre ideal for precision CNC work in space-limited environments. It features a HAAS 5C 4th-axis indexer to expand machining capability and increase flexibility. Renishaw Table and Spindle Probing, Swarf Auger, and Tooling Package. Equipped with Fanuc CNC control, this machine supports up to 10,000 RPM spindle speed and offers travels of X = 406 mm, Y = 305 mm, and Z = 254 mm. The working table measures 900 mm × 310 mm

Included

  • 4th Axis
  • Renishaw Probing
  • Swarf Auger
  • Tooling Package

Specifications

Manufacturer
HAAS
Year
2010
Control
Haas
Weight
1,542 kg
Dimensions
2,032 x 1,626 x 2,540 mm
X
406 mm
Y
305 mm
Z
254 mm
Power
11.2 kW
RPM
10000.0 rpm
# ATC
10.0
Taper
BT40
Table-W
305 mm
Table-L
914 mm
# Axis
3.0

As supplied by the seller. Figures are converted between systems where a unit applies; anything without one is shown as quoted.
